Hydraulic swing gate closer and bearing hinge in one. An elegantly designed self-closing hinge that opens smoothly and closes consistently gates up to 150 kg and this regardless of the outside temperatures (patented system). Force, closing speed and final snap are all individually adjustable according to your needs. Probably the best self-closing hinge on the market!

• Self-closing hinge with patented hydraulic damping
• Adjustable closing speed & closing pressure
• Easy mounting with Quick-Fix
• Adjustable freerun for perfect closing (final snap)
• For left and right opening gates
• Opening angle: 180°
• Powdercoated aluminium casing
• Double stainless steel bearing
• 2-dimensionally adjustable (2 x 20 mm)
• For gates up to 150 kg (max 1,2 m wide)
• Easy to open: Max. 15 Nm of force
• Conforms to all regulations regarding max allowed forces to open gates
• Ideal in combination with magnetic and mechanical locks
• Bottom Dino hinge included
• Especially designed for exterior use: rain & frost-proof
• Aesthetic design
• Burglar proof and anti-theft
• Closing speed unaffected by temperature changes
